CUDNER & O'CONNOR COMPANY
| 4035 West Kinzie Street | Chicago, IL 60624 | Phone: 773 826-0200 |
SGV/VC Series
True Fusion System
STANDARD COLORS
SGV Gloss ink is a true fusion formulation that offers optimum adhesion to rigid, semi-rigid and flexible vinyls. SGV prints beautifully and dries fast to a flexible finish making it ideal for extended use films such as Scotchcal. Also recommended for polycarbonates and other plastics.
White*
Black*
Lead Free Medium Yellow*
Navy Blue*
Ultra Blue*
Lead Free Primrose Yellow*
Lead Free Medium Green*
Fire Red*
Lead Free Orange*
Maroon*
Deep Red*
Perma Green*
Brilliant Perma Blue*
Lead Free Emerald Green*
Light Blue*
Lemon Yellow*
Lead Free Flag Red*
SGV-703 SGV-704
SGV-706LF SGV-707
SGV-708 SGV-709LF
SGV-712LF SGV-713LF
SGV-714LF SGV-719
SGV-723LF SGV-725
SGV-728 SGV-790
SGV-791LF SGV-792LF
SGV-794LF
SUBSTRATES
Flexible pressure sensitive vinyls:
Cast and Calendared outdoor films such as ScotchcalÒ, AveryÒ, MeyercordÒ, and General FormulationsÒ
Rigid Sheet Vinyl and expanded foam vinyl graphics panels such as SintraÒ, TrovicelÒ, CeltecÒ, and Vekaplan.
Also recommended for: Lexan, Makrofol and other vinyl coated polycarbonates, acrylics and other substrates
MODIFIERS | CLEARS
Screening Thinner SGV-701
Spraying Thinner CM-9840
Retarder Use SGV-720 to slow in-screen drying.
Excess use of retarder will inhibit drying of the printed panel.
Flow Promoter SGV-11335
Screen Wash SGV-710
Additional Clears
Mixing Clear: SGV-702
Clear: SGV-721
Drying
SGV/VC inks dry through solvent evaporation. Fresh air volume is more of a factor in dry time than temperature.
Force Dry:
For high volume air dryer (3000 - 5000 cfm, equipped with air knives) at 100 -120°F: 30 - 60 seconds.
Air Dry: l5 - 45 minutes depending on air circulation and temperature.
Equipment: Batch oven with convection air or industrial conveyor dryers (non-textile) are preferred. lR panels may provide sufficient cure if belt will accommodate parameters above.
SCREEN MESH
160 to 305+
Polyester Monofilament
STENCILS
Direct method
emulsions, capillary films
SQUEEGEE
All types, 60 to 80 durometer
Note: lnformation contained in Cudner & O’Connor product sheets is based on laboratory and field tests. Because we cannot control actual production conditions, no warranty is expressed or implied. Careful testing is always recommended prior to production. Consult with our Technical Services Department on all application issues.
COVERAGE
Approximately 1200 - 1500 Sq, Ft / Gal.
Process Yellow LF*
Mixing Orange*
Rubine*
Rhodamine*
Purple*
Reflex Blue*
Cyan*
Green*
Mixing White*
Mixing Black*
Mixing Clear*
MIXING COLORS
SGV-MS01
SGV-MS02
SGV-MS03
SGV-MS04
SGV-MS05
SGV-MS06
SGV-MS07
SGV-MS08
SGV-MS09
SGV-MS10
SGV-MS11
METALLICS
Pale Gold*
Rich Pale Gold*
Rich Gold*
Silver*
Bright Silver*
SGV-734
SGV-735
SGV-736
SGV-737
SGV-733
* Heavy metal compliant
LF - Lead Free.
