CUDNER & O'CONNOR COMPANY
| 4035 West Kinzie Street | Chicago, IL 60624 | Phone: 773 826-0200 |
SS/BC Series
Flexible Lacquer
STANDARD COLORS
A fast drying, high gloss graphics ink designed for flexible substrates such as paper, water-slide decals, leather and Tyvek. Flexible and easy to use. Displays excellent die-cutting characteristics. Available in 4-color process systems (CPl Series).
Overprint Clear*
Satin Clear
Flat Clear
Halftone Clear
White*
Flat White*
Hi Cover White*
Super Hi Cover White* Super Hi Cover White*
Black*
Hi Cover Black*
Primrose Yellow LF*
Fire Red*
Magenta*
Lemon Yellow LF*
Medium Yellow LF*
Orange LF*
Flag Red LF**
Ultra Blue*
Brilliant Perma Blue*
Perma Green*
Medium Green LF*
Dark Brown*
Deep Red*
Navy Blue*
Light Brown*
Flat Black*
Emerald Green LF*
Light Blue*
Maroon*
SS-1100
SS-1140
SS-1122
SS-1125
SS-1101
SS-1104
BC-8955
BC-12657
BC-37706
SS-1102
BC-8902
SS-1106LF
SS1107LF
SS-1108
SS-1109FL
SS-1110FL
SS-1111FL
SS-1112FL
SS-1113
SS-1114P
SS-1115
SS-1118LF
SS-1121
SS-1124
SS-1127
SS-1129
SS-1130
SS-1190LF
SS-1191
SS-1196
SUBSTRATES
Coated paper stock: Where gloss, flexibility and die-cuttability are desirable. CPI Halftone Base and Toners are recommended for 4-color process work on posters and POS. Works well on foam board materials with clay coated paper lines.
Water Slide Decals: SS is the ink of choice for this resurging medium.
Banner Materials such as Tyvek
Leather | Wood | Metals
MODIFIERS | CLEARS
Screening Thinner T-804
Spraying Thinner CM-9840
Retarder T-22
Flow Promoter CM-9775
Screen Wash W-110
Additional Clears
Mixing Clear: L-318
Fast Dry Clear: L-366
Non Gel Clear (for Metallic Pigments): L-345
Drying
SS Lacquers dry through solvent evaporation. Fresh air volume is more of a factor in dry time than temperature.
Force Dry:
For high volume air dryer (3000 - 5000 cfm, equipped with air knives) at 100 -120°F: 30 - 60 seconds.
Air Dry: l5 - 45 minutes depending on air circulation and temperature.
Equipment: Batch oven with convection air or industrial conveyor dryer (non-textile) are preferred. lR panels may provide sufficient cure if belt will accommodate parameters above.
SCREEN MESH
160 to 305+
Polyester Monofilament
STENCILS
Direct method
emulsions, capillary films
SQUEEGEE
All types, 60 to 80 durometer
Note: lnformation contained in Cudner & O’Connor product sheets is based on laboratory and field tests. Because we cannot control actual production conditions, no warranty is expressed or implied. Careful testing is always recommended prior to production. Consult with our Technical Services Department on all application issues.
COVERAGE
Approximately 1200 - 1500 Sq, Ft / Gal.
Process Yellow LF*
Mixing Orange*
Rubine*
Rhodamine*
Purple*
Reflex Blue*
Cyan*
Green*
Mixing White*
Mixing Black*
Mixing Clear*
MIXING COLORS
SS-MS01LF
SS-MS02
SS-MS03
SS-MS04
SS-MS05
SS-MS06
SS-MS07
SS-MS08
SS-MS09
SSMS-10
SSMS-11
METALLICS
Pale Gold*
Rich Pale Gold*
Rich Gold*
Silver*
Bright Silver*
SS-1134
SS-1135
SS-1136
SS-1137
SS-1133
* Heavy metal compliant
LF - Lead Free.
