PE Series
THERMAL SET POLYESTER INKS FOR METAL
STANDARD COLORS
For exterior use. PE Series offers excellent adhesion and flexibility for metal applications. This high gloss formulation is also recommended for general OEM use, nameplates, automotive and equipment panels. Superior flexibility and chemical resistance. Complies with 0T 180° bend performance standard.
May be reduced for direct or reverse roller coating, coil coating and spraying.
Halftone Clear*
Topcoat*
White*
Black*
Primrose Yellow LF*
Lemon Yellow LF*
Medium Yellow LF*
Orange LF*
Fire Red LF*
Flag Red LF*
Deep Red LF*
Magenta*
Light Blue*
Perma Blue*
Navy Blue*
Ultra Blue*
Emerald Green*
Perma Green*
Iron Oxide Yellow*
Iron Oxide Red*
Iron Oxide Black*
PE-801
PE-802
PE-803
PE-804
PE-805LF
PE-806LF
PE-808
PE-810
PE-812
PE-813
PE-815-LF
PE-816
PE-817
PE-818
PE-819
PE-820
PE-821
PE-822
PE-823
PE-824
PE-835
SUBSTRATES
Glass | metals | anodized, mill-finished and coated aluminum
Compliant with Title 2l CFR I 75.300
(incidental food contact.)
Special primers and top coats are available for increased flexibility and chemical resistance (see descriptions below).
SPECIAL PRIMERS & TOPCOATS
EP-301 Topcoat: For use over colors. Enhances chemical and abrasion resistance; approved for use in appliances.
EP-304 Topcoat: For Non-Yellowing over white.
EP-306 Additive: For formed parts, improves flexibility of subsequent colors.
Simulated Etch for Glass*: EP-34155
Matte Clear for Metal*: EP-34155
MODIFIERS
Reducer: EP-360 Reducer
Retarder: Use 5-10% EP-321 Retarder to slow drying in screen
Flow Additive: Use 1-2% EP-320 to promote leveling
Catalyst: EP-350
SCREEN WASH
Use EP-310
BAKE/CURE
Bake Dry:
300°F for 15 minutes
350°F for 8 minutes
400°F for 4 minutes
Flash-off 30 seconds at 500°F.
Equipment: Batch oven with convection air or industrial conveyor dryer (non-textile) are preferred. lR panels may provide sufficient cure if belt matches parameters above.
SCREEN MESH
260 to 355
Polyester Monofilament
STENCILS
Direct method
emulsions,
capillary films
SQUEEGEE
All types, 60 to 80 durometer
Note: lnformation contained in Cudner & O’Connor product sheets is based on laboratory and field tests. Because we cannot control actual production conditions, no warranty is expressed or implied. Careful testing is always recommended prior to production. Consult with our Technical Services Department on all application issues.
COVERAGE
Approximately 1200 - 1500 Sq, Ft / Gal.
Transparent Yellow*
Transparent Orange*
Transparent Red B*
Transparent Magenta*
Transparent Violet*
Transparent Blue*
Transparent Green*
Transparent Red Y*
TRANSPARENT COLORS
PE-831
PE-832
PE 833
PE-834
PE-835
PE-836
PE-837
PE-838
METALLICS
Pale Gold*
Rich Gold*
Silver*
Bright Silver*
Rich Pale Gold*
PE-826
PE-827
PE 828
PE-829
PE-851
*Heavy metal compliant
