PA Series
Acrylic Multi-Use Ink
STANDARD COLORS
PA Poly Acrylic Ink offers superb all-around performance for fleet marking, indoor and outdoor signage, general POS, metal parts and poster printing. This is a fast drying ink with good gloss, flexibility, good outdoor performance and is vacuum formable.
White*
Hi Cover White*
Black*
Ultra Blue*
Medium Yellow LF*
Navy Blue*
Primrose Yellow LF*
Medium Green LF*
Fire Red LF
Orange LF*
Light Brown*
Maroon*
Flag Red LF*
Deep Red LF*
Perma Green*
Brilliant Perma Blue*
Emerald Green LF*
Light Blue*
Lemon Yellow LF*
Dark Brown
PA-603
PA-14940
PA-604
PA-605
PA-606LF
PA-607
PA-609LF
PA-612LF
PA-613LF
PA-114LF
PA-615
PA-619
PA-622LF
PA-623LF
PA-625
PA-628
PA-690LF
PA-691
PA-692LF
PA-695
SUBSTRATES
Plastics: including: Acrylics such as Plexiglass and Lucite; rigid, semi-rigid and flexible vinyls, especially fleet marking films by 3M, Avery and Flexcon, foamed vinyl sheets such as Sintra, Trovicel, etc. Other plastics: styrene, top-coated or otherwise print treated polyester, polycarbonates such as Lexan.
Other substrates:
Metal: (Coated and uncoated) | Glass
| Foam Board
| Paper (coated and uncoated)
Wood
MODIFIERS
Reducer/Thinner: PA-601 to achieve
desired viscosity
Retarder PA-621 Retarder to slow in-screen drying NOTE: Excessive use of retarder may inhibit drying of the printed film.
Flow Promoter: PA-620 or PA-620C Concentrate to improve ink flow out
Clear: PA-602
Sharp Print Compound: PA-640
Clear Spray Base: PA-646
Spray Thinner: PA-647
Screen Wash: PA-610
DRYING
PA Series inks dry through solvent evaporation. Fresh air volume is more of a factor in dry time than temperature.
Force Dry:
For high volume air dryer (3000 - 5000 cfm, equipped with air knives) at 100 -120°F: 30 - 60 seconds.
Air Dry:
15 - 45 minutes depending on air circulation and temperature.
Equipment: Batch oven with convection air or industrial conveyor dryer (non-textile) are preferred. lR panels may provide sufficient cure if belt will accommodate parameters above..
SCREEN MESH
160 to 300+
Polyester Monofilament
STENCILS
Direct method
emulsions, capillary films
SQUEEGEE
All types, 60 to 80 durometer
Note: lnformation contained in Cudner & O’Connor product sheets is based on laboratory and field tests. Because we cannot control actual production conditions, no warranty is expressed or implied. Careful testing is always recommended prior to production. Consult with our Technical Services Department on all application issues.
COVERAGE
Approximately 1200 - 1500 Sq, Ft / Gal.
Process Yellow LF*
Mixing Orange*
Rubine*
Rhodamine*
Purple*
Reflex Blue*
Cyan*
Green*
Mixing White*
Mixing Black*
Mixing Clear*
MIXING COLORS
PA-MS01LF
PA-MS02
PA-MS03
PA-MS04
PA-MS05
PA-MS06
PA-MS07
PA-MS08
PA-MS09
PA-MS10
PA-MS11
METALLICS
Pale Gold*
Rich Pale Gold*
Rich Gold*
Silver*
Bright Silver*
PA-634
PA-635
PA-636
PA-637
PA-639
* Heavy metal compliant
LF - Lead Free.
