KP Series
Industrial Lacquer
STANDARD COLORS
KP Lacquers combine beautiful screening characteristics with a versatile, high-performance formulation. For metal, glass and a wide range of plastics. Display a pleasing hard gloss finish and excellent screen stability. Force dry in under a minute. Now available in mixing colors.
White*
Hi Cover White*
Black*
Medium Yellow LF*
Primrose Yellow LF*
Orange LF*
Ultra Blue*
Brilliant Perma Blue
Perma Green*
Medium Green LF*
Deep Red*
Navy Blue*
Light Brown*
Emerald Green LF*
Light Blue*
Lemon Yellow LF
Fire Red LF
Flag Red LF*
Dark Brown*
Maroon*
KP-2103
KP-2150
KP-2104
KP-2106LF
KP-2109LF
KP-2111LF
KP-2113
KP-2114
KP-2115
KP-2118LF
KP-2124
KP-2127
KP-2129
KP-2190LF
KP-2191
KP-2192LF
KP-2193LF
KP-2194LF
KP-2195
KP-2196
SUBSTRATES
Metal: Test metal prior to production. Use up to 5% KP-2001 Metal etch thinner to improve adhesion.
Plastics: Especially acrylics (Plexiglas, Lucite), vinyl sheets, Scotchlite reflective tapes, topcoated polyester, polycarbonates, styrene.
Top coatings affect adhesion. Avoid Polyethylene.
Glass: Recommended for first or second-surface printing (depending on application); can be used for second-surface graphics on glass prior to mirroring/silvering process.
Other Substrates: Coated paper, foam boards and wood.
MODIFIERS
Thinner: KP-2000 to achieve desired viscosity
Clear: KP-2002
Low-Acid Mixing Clear: KP2121
Flow Promoter: CM-9775
Flat Extender: KP-2017
Retarder KP-2020 Retarder to slow in-screen drying.
NOTE: Excessive use of retarder may inhibit drying of the printed film.
Metal Etching Thinner: KP-2001
Screen Wash KP-2010
Drying
KP Lacquers dry through solvent evaporation. Fresh air volume is more of a factor in dry time than temperature.
Force Dry:
For high volume air dryer (3000 - 5000 cfm, equipped with air knives) at 100 -120°F: 30 - 60 seconds.
Air Dry: 15 - 45 minutes depending on air circulation and temperature.
Equipment: Batch oven with convection air or industrial conveyor dryer (non-textile) are preferred. lR panels may provide sufficient cure if belt will accommodate parameters above.
SCREEN MESH
160 to 305+
Polyester Monofilament
STENCILS
Direct method
emulsions, capillary films
SQUEEGEE
All types, 60 to 80 durometer
Note: lnformation contained in Cudner & O’Connor product sheets is based on laboratory and field tests. Because we cannot control actual production conditions, no warranty is expressed or implied. Careful testing is always recommended prior to production. Consult with our Technical Services Department on all application issues.
COVERAGE
Approximately 1200 - 1500 Sq, Ft / Gal.
Process Yellow LF*
Mixing Orange*
Rubine*
Rhodamine*
Purple*
Reflex Blue*
Cyan*
Green*
Mixing White*
Mixing Black*
Mixing Clear*
MIXING COLORS
KPMS-01LF
KPMS-02
KPMS-03
KPMS-04
KPMS-05
KPMS-06
KPMS-07
KPMS-08
KPMS-09
KPMS-10
KPMS-11
METALLICS
Bright Silver*
Pale Gold*
Rich Pale Gold*
Rich Gold*
Silver*
KP-2123
KP-2134
KP-2135
KP-2136
KP-2137
* Heavy metal compliant
LF - Lead Free.
